OV Series Manual Pinch Valve 2-1/2" - OV065.04L.30M
Series OV handwheel pinch valve (part number: OV065.04L.30M) with a nominal diameter of 2-1/2". Equipped with a EPDM (food, gray) sleeve, Flange (DIN) connections and an Aluminum body.
Specifications
| Nominal Diameter | 65mm, 2-1/2" |
| Drive Type | Handwheel |
| Max. Operating Pressure | 75 psi |
| Min. Operating Temperature | 14° F |
| Max. Operating Temperature | 194° F |
| Body Material | Aluminum |
| Connection Type | Flange (DIN) |
| Sleeve Quality | EPDM (food, gray) |
