Titan 800 Series - PVDF - Calibrated
Titan 800 Series - PVDF - Calibrated
Ships in ~4 weeks
The Titan 800 Series Mini Turbine Flow Meter is an NSF/ANSI 169 certified flow meter for low-viscosity liquids used in food and beverage, batching, dosing, laboratory, and OEM systems. This version uses a PVDF body with non-metallic wetted components and sapphire bearings.
Features
- Six flow ranges from 0.05 to 15 L/min
- NSF/ANSI 169 certified for food-equipment applications
- Non-metallic wetted construction
- Sapphire bearings
- Hall-effect sensing
- NPN pulse output is standard; the NPN/PNP output option is limited to configurations below 60°C
- 0.1% repeatability
- IP65 enclosure rating
Technical Specifications
- Body material: PVDF
- Overall flow range: 0.05–15 L/min across six models
- Linearity: 1–2% FSD depending on selected flow range
- Pressure rating: 10 bar
- Power: 4.5–24 VDC
- Temperature: -25 to 125°C, configuration dependent
- Standard seal: Viton™; other seal materials are available
- Connections: Hose-tail and alternative connection options are available
- Calibration status: Calibrated
Typical Applications
- Food and beverage equipment
- Drink dispensing
- Liquid batching and dosing
- Aggressive chemicals and ultra-pure water
- Laboratory and cooling equipment
- Semiconductor and OEM systems
Configuration Options
This product is the calibrated PVDF body version. Select the required flow range, seal material, and output/connection configuration. The NPN/PNP output option is limited to configurations below 60°C. Select wetted materials and seals for compatibility with the process liquid.
Need help selecting the right configuration? Send us the liquid, minimum and maximum flow, viscosity, pressure, temperature, and connection requirements.
